PANALIVE
Strong adhesive film
PANALIVE is a strong adhesive film based on polyester film. There are many types of PANALIVE and they have been developed to be widely used for diversifying adhesive needs.
-
Strong adhesive film
L・Y・Z・MFC・YAP
Features FEATURES
-
PANALIVE has excellent adhesion, heat resistance and processability, and it is possible to paste to all parts and materials by choosing the optimum type.
Composition COMPOSITION
Standard type STANDARD TYPE
| Type | Base film | Adhesivestrength(N/cm) | Features | Application |
|---|---|---|---|---|
| L | PET | 5.5 | Excellent adhesion for polyolefin, rough or curved surface | Reinforcement・Label |
| Y | PET | 5.1 | General strong adhesive purposes(Colored base film type,colored adhesive type are available.) | Membrane・Spacer・Reinforcement・Insulation・Overlay |
| Z | PET | 5 | Low metal corrosiveness. Excellent processability. | Metal parts fixing・Membrane・Spacer |
| MFC | Copper foil(35μm) | 4.4 | Excellent adhesion for variousadherend | Shielding |
| YAP | AL-PET10-25 （Adhesive on PET side） | 4.9 | Due to the composite product of PET and aluminum foil, it is tough and has excellent processing characteristics. |
※Measurement condition: Peeling speed 200mm/min, Peeling angle 180°
※The indicated values are measurement values, not guaranteed values.
Other information OTHER
-
It is available for choosing the thickness of the base film (PET).
-
One side adhesive and double side adhesive processing are possible.
-
Paper, film, etc. can be selected as release film.
-
Stripe adhesive processing is possible.
